PRE-STUDIO-24C
PreSonus Studio 24c USB-C Audio Interface
Great for recording studios, mobile musicians, guitarists, podcasters, and live streaming, the bus-powered Studio 24c 2-in, 2-out audio interface features 2 front-panel combo mic/line/instrument inputs with PreSonus® XMAX-L solid-state mic preamps, 2 rear-panel line outputs, MIDI I/O, and onboard direct monitoring control. A complete, all-in-one home recording studio, the Studio 24c comes with PreSonus’ award-winning Studio One® Artist music production software & Ableton Live Lite for macOS® and Windows®.
Type: USB-C Audio Interfaces
Product Features:
Input/Output
Simultaneous I/O up to 2 inputs/2 outputs
2 mic/instrument/line inputs with XMAX-L mic preamps
2 balanced ¼” TRS main outputs
1 stereo headphone output
MIDI In/Out
Meters, Controls, and Features
Mixer knob for low-latency direct input monitoring
Front-panel level controls for main outputs
+48V phantom power for condenser microphones (global)
4 ladder-style LED level meters (2 input, 2 main output)
Integrated Software
Studio One Artist®
Studio Magic Plug-in Suite
Digital
USB-C port (USB 2.0)
24-bit resolution
44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
Physical
Road-rugged construction with all-metal chassis and metal knobs
USB bus-powered
Tech Specs:
General |
|
|---|---|
| Sample Rates | 44.1, 48, 88.2, 96, 176.4, or 192 kHz |
| Converter Resolution | 24 bit |
| ADC Converter Dynamic Range | 108 dB |
| DAC Converter Dynamic Range | 108 dB |
Microphone Inputs |
|
|---|---|
| Maximum Level | +10 dBu (±0.5 dBu, min gain) |
| Gain Range | 50 dB |
| Frequency Response | 20 Hz - 20 kHz (±0.3 dBu, unity gain, unwtd) |
| Dynamic Range | 106 dB (A-wtd, min gain) |
| THD + N | 0.004% (1 kHz, -1 dBFS, min gain) |
| EIN | -126 dBu (A-weighted, 150Ω, max gain) |
| Input Impedance | 1.4 kΩ |
| Phantom Power | +48 VDC (10 mA total) |
Instrument Inputs |
|
|---|---|
| Maximum Level | +19 dBu (min gain) |
| Gain Range | 50 dB |
| Frequency Response | 20 Hz – 20 kHz (±0.1 dBu, unity gain, unwtd) |
| Dynamic Range | 105 dB (A-wtd, unity gain) |
| THD + N | 0.002% (1 kHz, min gain) |
| Input Impedance | 750 kΩ |
Main Outputs |
|
|---|---|
| Type |
¼" TRS, Female |
| Maximum Level | +10 dBu (1 kHz, unity gain, balanced) |
| Frequency Response | 20 Hz – 20 kHz (±0.3 dBu, unity gain, unwtd) |
| Dynamic Range | 104 dB (unity gain, unwtd) |
| THD + N | 0.001% ( 1 kHz, -1 dBFS, unity gain) |
Headphone Outputs |
|
|---|---|
| Maximum Power | 47 mW / channel @ 56Ω |
| Frequency Response | 20 Hz – 20 kHz (±0.5 dBu, unity gain, unwtd) |
| Dynamic Range | 83 dB (A-wtd, 56Ω load) |
| THD + N | 0.01% (1 kHz, 0 dBFS, loaded) |
| Impedance Working Range | 32Ω to 300Ω |
Physical |
|
|---|---|
| Height | 1.75" (44 mm) |
| Width | 7" (180 mm) |
| Depth | 5.5" (144 mm) |
| Weight | 2 lbs. (0.9 kg) |
System Requirements:
Mac
Mac® OS X 10.8.5 64-bit or later
Intel® i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Windows
Windows® 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, Windows 10 x64/x86
Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
Mac and Windows Systems
USB-C or USB-A 2.0 port
32 GB hard disk space
PreSonus Universal Control 2.0 or higher
Monitor with 1366x768 resolution (high-dpi monitor recommended)
Multitouch-enabled monitor required for touch operation
** Please note, system requirements may change. For the most recent system requirements please visit the manufacturer's official product listing **
