RICOCHET

Digitech Whammy Ricochet Pitch Shift Pedal

6 In Stock

The DigiTech Whammy Ricochet, is a stomp-box style pitch shifting guitar pedal. The Ricochet allows you to choose from 7 different pitch selections ranging from a tone, right up to a double octave. By holding down on the foot-switch you can activate the pitch shift without using a treadle. Other features include an LED meter that depicts the pedals pitch movements, programmable rise-and-fall times, and latch mode. Latch mode can be used to maintain the destination pitch.


    • DigiTech Whammy Ricochet Features:

      Famous Whammy™ sound without a bulky treadle
      Bend notes up or down across 2 octaves
      7 Selectable Pitch intervals
      Ultimate control of Shift and Return time
      LED Trajectory Ladder provides instant visual feedback
      Classic and Chords mode
      Momentary or Latching footswitch
      True Bypass in latching mode
    • DigiTech Whammy Ricochet Specifications:

      Input: 1/4” Unbalanced (Tip-Sleeve)
      Max Input Level: +5 dBu
      Input Impedance: 1 MΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off)
      Output: 1/4” Unbalanced (Tip-Sleeve)
      Max Output Level: +10 dBu
      Output Impedance: 1 kΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off)
      Controls: Ballistics Control, Pitch Control, Range Switch, Momentary Switch, Effect On/Off
      Sample Rate: 44.1 kHz in classic mode, 22 kHz in chords mode
      Frequency Response: 20 Hz–16 kHz (classic mode), 20 Hz–11 kHz (chords mode)
      Signal to Noise Ratio: > -106dB (A weighted); ref = max level, 22 kHz bandwidth
      A/D/A Converter: 24-bit
      THD: 0.004% @ 1 kHz; ref = 1 dBu w/ unity gain
      Power Consumption: 2.1 Watts (235 mA typical @ 9 VDC)
      Power Requirements: 9 VDC External Adapter (sold separately)
      Power Supply: PS0913DC-01 (US, JA, EU); PS0913DC-02 (AU, UK)
      Power Adapter Output: 9 VDC 1.3 A
      Weight: 0.80 lbs. (0.363 kgs.)
      Dimensions: 4.75” (L) x 2.875” (W) x 1.75” (H)
