Grace Design m108 8 x 2 USB Audio Interface with 8 Mic Preamps, 8 A/D Converters, and AES and ADAT Output

With eight channels of our transparent, musical mic preamplification, state of the art A/D conversion, multiple digital output formats, and flexible local or remote controlled operation, the m108 is a vital addition to any modern audio production environment. Based on the acclaimed success of the m802 remote controlled mic preamplifier, the m108 distills the best of these achievements into a sleek, elegant 1U chassis design. The transformerless, transimpedance mic preamp design is unmatched in its ability to effortlessly resolve complex sonic waveforms, resulting in recordings of amazing clarity and depth. Integrated A/D conversion delivers digital signals to the workstation that are pure and beautiful. Latest generation s-Lock PLL ensures pristine, jitter free sample clock when clocking from external word clock or Dante clock. And an asynchronous mode USB interface provides the best possible jitter performance when connected to a computer.

• 8 channels of balanced analog preamp outputs
• 8 channels of transparent, musical mic preamplifier
• Wide gain range: -6 to 69dB
• Ribbon mic mode
• 8 channels of 192kHz ADC outputs via AES, ADAT (4ch SMUX) and USB Class 2
• External Word clock in and out
• Reference DAC and headphone amplifier for low-latency monitoring of channel pairs or USB playback from a computer
• Channel 1 & 2 HI-Z inputs on front panel
• High contrast, wide viewing angle OLED display for all system parameters and setup menu
• Combination RS 485/422 serial / MIDI ports for control from existing m802 RCU or Protools™
• Control App (Win and Mac, coming soon) can control up to 96 channels over Ethernet
• Simple web browser control built in, works with all modern browsers including iOS and Android
• RJ45 Ethernet port for network control
• Expansion slot for optional Audinate / DANTE™ network audio card
• Cooling fan for reliable operation in the harshest environments
• Built in 100-240VAC universal AC power supply
• 5 year transferable warranty
• Made in the USA
