AEA84
Get that subtle ribbon sound without breaking the bank. The R84 is your ticket to ribbon heaven. The AEA R84 is an affordable Large Ribbon Geometry (LRG) microphone suitable for use by the most demanding audio professional or hobbyist. This "R84 Zone" is for you and other users to share your experiences. We expect to expand this area with practical illustrations, guides to tracking situations, and actual recording experiences. Our intention is to encourage and support your success and satisfaction as you become familiar with this mic's unique features. Drop us an e-mail to share your experiences, or if you want to be informed when we post new, practical information here.
Type: Ribbon Mics
Operating Principle: Velocity microphone
Frequency Response: 20 Hz to 20 kHz
Maximum SPL: 165 + dB SPL above 1 kHz for 1% third harmonicOutput Sensitivity: -52 dBv/Pa
Output Impedance: 270 Ω nominal
Recommended Load: 1.2 kΩ or greater
Powering: Not required or recommended
Polarity: Pin 2 high for positive pressure on front of microphone.Connector: XLR-3M wired to a 3 m captive cable
Off Axis Response:
Polar Pattern: Native bi-directional pattern
Horizontal: Level changes with angle, frequency response is consistent,
–35 dB null at 90° / 270°
Vertical: Level changes with angle, reduced HF response above and
below 0° / 180° axis, –35 dB null at 90° / 270°
Transducer element
Ribbon Thickness: 1.8 μ (0.0000018 m) of pure aluminumRibbon Width: 4.7 mm
Ribbon Length: 59.7 mm
Accessories:
Included: Custom storage / shipping case, manual
Optional: Any length cable, inquire for price and delivery.Custom laser engraving with your art or logo
Limited Warranty:
Weight: 3 pounds in storage case with cable Length: 11.6”, Width: 3.9”, Depth: 2.5”
Options
DJV Designed for close vocal work and includes greater internal sheilding against plosives.
One year parts and labor, shipping not included.
